Instantaneous water heater for showers
TP 45 EC (VN)

    • More water flow with powerful and super quiet booster pump
    • Anti-scalding and overheating protection with double action thermostat
    • 5-in-1 shower head with slide bar for convenient height adjustment
    • Extra slimline design with a depth of just 7.3 cm
    • Complete set optimised for a single shower
    • Protection from electric shock with Earth Leakage Circuit Breaker (ELCB)
    • Protection class IP25 (splash-proof)
    • Temperature adjustment via stepless power control
    Questions about the product Get contact

    Product details

    APPLICATION: Electric instantaneous water heater with booster pump and shower head set – the complete solution for single showers. Domestic hot water is provided instantly at the shower, without waiting.

    EQUIPMENT & CONVENIENCE: Shower unit with booster pump, featuring steplessly adjustable power control up to the rated maximum power. The shower head features 5 different spray settings ranging from gentle to massage and is mounted on a slide bar for convenient height adjustment. The booster pump increases the water pressure and output volume. Suitable for homes with very low water pressure.

    INSTALLATION: Quick and easy installation. Drilling template provided. Splash-proof.

    SAFETY & QUALITY: Highest electrical safety certified to international standards guarantees trouble-free operation. The Earth Leakage Circuit Breaker (ELCB) detects any harmful leakage current and shuts off the power supply, thereby providing full protection from electric shock. Anti-scalding protection with integrated thermal cut-out to limit the water outlet temperature. The flame-retardant electronic circuit board and pressure-resistant copper tank provide additional safety and durability. The heating element is made from corrosion-resistant copper for superior durability and maintenance-free operation, even in chlorinated water.


    Reach-Information
    Technical datasheet

    Product Number: 207527

    Electrical fuse protection: ELCB

    Rated output: 4,500 W

    Electrical connection: 1/N/PE~220-240 V

    Rated voltage: 220-240 V

    Heating element: Copper

    Type: Open outlet

    Heating material: Copper

    Temperature setting: Stepless

    Temperature control: Output control

    Anti-scalding protection: Double acting thermostat

    Shower accessories: 5-in-1 shower head with slide bar

    Colour: black

    IP rating: IP25

    Depth: 73 mm

    Height: 342 mm

    Width: 216 mm

    Weight: 1.7 kg

    Show all

    Download as PDF

Installation Information:

Please ask your local power supply utility or a registered electrician to install appliances that are not fully wired, i.e. ready to plug in. The electrician should also be able to assist you with obtaining the agreement of the respective power supply utility required for the appliance installation.
